ColorBright™️ Vivid Color Series LED Strip Light
Our newly reinvented ColorBright™ Vivid Color LED Strip Lights offer stunning accent lighting options in red, green, blue, or amber hues. With enhanced color saturation and depth, their inviting brightness will elevate both residential and commercial indoor spaces requiring soft illumination in static colors.
This product is ideal for mood lighting in residential spaces. From thematic display cabinets to showcasing textured walls or wallpaper, this flexible, vibrant solution will add beautiful, delicate splashes of color from behind bed frames, under kitchen cabinets, along coves, or below bar counters, among others.
This strip light will greatly benefit commercial locations seeking vibrant colored lighting, such as restaurants, hotels, bars, casinos, retail locations, and entertainment venues. It is the best option for colorful hospitality embellishments, indoor signage, backlighting, and decorative displays.
Top Features and Benefits:
-
✔ Available in red, green, blue, and amber colors
-
✔ 15-year Warranty
-
✔ 50,000 Hour Lifespan (8 hours a day for 17 years)
-
✔ Thermally resistant 3M VHB 4930 adhesive
-
✔ Fully dimmable
-
✔ Short LED pitch of 1/4"(7 mm)
-
✔ Single BIN LED selection to ensure color consistency
-
✔ Highest quality components packaged 3528 SMD LEDs
-
✔ UL Listed
-
✔ 120° beam angle
Applications and Use:
These strips are installed in a wide variety of applications including:
-
• Cove lighting
-
• Restaurant lighting
-
• General accent lighting
-
• Christmas and holiday lighting
-
• Stage lighting
-
• Linear lighting
-
• Backlighting
-
• Edge lighting
-
• Cabinets and shelves
-
• Commercial signage lighting
Why choose ColorBright™️ Vivid Color Series LED Strip Light:
Specifications:
-
✔ 3 Watts/ft
-
✔ 15-year warranty
-
✔ 50,000-hour lifespan (8 hours/day for 17 years)
-
✔ Width: 3/8" (10 mm)
-
✔ Height: 1/8" (2.5 mm)
-
✔ Can be cut every 2"
-
✔ Max length in series 32' 10"
-
✔ Fully dimmable
-
✔ 120° beam angle
-
✔ 24V DC input voltage
-
✔ 36 LEDs/Foot (120/Meter)
-
✔ Thermally resstant 3M VHB 4930
-
✔ Short LED pitch of 1/4" (7 mm)
-
✔ Highest quality premium packaged 3528 SMD LEDs
-
✔ Thick double layer 4oz copper PCB
-
✔ Single BIN LED selection to ensure color consistency
-
✔ IP20 Rated for indoor use, dry locations
-
✔ Ambient Temperature -4°F - 113°F (-20°C - 45°C)
-
✔ UL Listed
| Product SKU | Color | Watts / Foot | Lumens / Foot | Luminous Efficacy | Color Wavelength |
| R-24V | Red | 3 W/ft (9.8 W/m) |
31 lm/ft (101 lm/m) |
10 lm/W | 630 nm |
| G-24V | Green | 3 W/ft (9.8 W/m) |
177 lm/m (581 lm/m) |
61 lm/W | 517 nm |
| B-24V | Blue | 3 W/ft (9.8 W/m) |
44 lm/m (143 lm/m) |
14 lm/W | 462 nm |
| A-24V | Amber | 3 W/ft (9.8 W/m) |
144 lm/ft (375 lm/m) |
39 lm/W | 641 nm |
| ATS-24V | Monochromatic Amber | 3 W/ft (9.8 W/m) |
67 lm/ft (221 lm/m) |
22 lm/W | 593 nm |
Certifications:
Aluminum Channels
Compatible Aluminum Mounting Channels
Dimmers and Home Automation
Compatible Dimmers and Controllers
Connectors
Extra Wire
20/2 2-Strand 20 AWG CMP-rated wire
16/2 2-Strand 16 AWG Cerrowire UL Listed
Power Supplies
Non Dimmable Drivers
Flexfire LEDs® Plug-in Power Supply
Mean Well™ HLG and LPV Hardwired Power Supplies
Dimmable Drivers
Zurik® Universal Dimmable Driver
Zurik® EMLV Dimmable LED Driver
Lutron Hi-Lume Dimmable Driver
ColorBright Vivid Color Series FAQ:
Q: What are the top 4 comparing factors to look for before purchasing LED strip lights?
1. Make sure you know the requirements for your project, then when looking at options, compare lumen output, CCT, and CRI.
2. Compare LED strip size and number of chips on the reel.
3. Understand the wattage and voltage that the LED strip light uses.
4. Make sure that the products have verifiable quality.
To read more details on these top considerations, click here.
Q: What is the importance of UL Listed?
UL is an acronym for the Underwriters Laboratories. They are an independent product safety certification organization. A good summary used by UL is, "a not-for-profit organization dedicated to public safety." This means you can install these LEDs in commercial spaces, industrial applications, and in your home with peace of mind.
Q: What is the product warranty?
We’re so happy with the quality of our product, we offer a 15-year warranty on most of our LED strips to all of our clients. The warranty on power supplies ranges from 2 to 7 years which is model dependent.
Q: What is the lifespan of your strip lights?
Our lights have been rigorously tested and have an expected lifespan of 50,000 hours before dropping to 70% luminosity. This means that if you were to use your lights 12 hours a day, every day, the lights would be expected to last longer than 10 years. Even after that time has elapsed, the lights will maintain a brightness of 70%. Higher-output strips require a heat sink to reach the expected lifespan and beyond.
Q: What is a 3528 SMD LED chip?
3528 SMD (Surface Mounted Diode) represents the size of the LED chips on the strip. A 3528 SMD chip measures 3.5 mm x 2.8 mm. Click here for more information on LED chip sizes.
Q: How do I mount the lights?
The 3M double sided adhesive that is found on the back of the LED strip allows you to install them in most locations. Be sure to thoroughly clean the surface to remove all dust and particulate matter before mounting the strip. Certain surfaces may require you to take additional measures to secure the strips lights into place. Feel free to call us with any questions.
Q: Can I cut the strips myself?
Yes, LED strips are made to be cut to your desired length. Using sharp scissors, you can cut the strip every few inches (on a line that's marked after every sixth LED).
Q: What do I need to turn on my lights?
To turn on LED strips, you will need to connect to a LED power supply. For connecting strips to the power supply we recommend soldering to make the strongest connections. Another option is to use our solderless connectors, which is a faster and easier way to install LED strips.
Q: Which wire gauge do I need?
Different setups require different wire gauges (wire thickness) for safety and performance. The current and run length will determine the exact gauge of wire needed for your project. Read here for more information on how to select the correct wire gauge for your LED strip light installation as well as managing voltage drop.
Q: Which power source do you need for my project?
Please refer to our LED Strip Light Power Supply Selector to choose the best power supply based on your application.
Q: What do I do if I want to dim my LED strip lights?
All LED strip lights are dimmable. The LED strips can be dimmed either through our PWM dimmers, or by a Lutron wall dimmer
To dim the lights you have two options:
1. If you plan to dim your LED strips using a hardwired Lutron wall dimmer, you need a Zurik dimmable driver. This driver itself will be dimmed from the Lutron switch.
2. If you do not plan to dim the lights from a hardwired wall dimmer and want to dim them with one of our dimmers, you will need a non-dimmable LED driver [Mean Well or Flexfire LEDs Brand].
