Mean Well™ HLG Series LED driver [40W - 600W available]

Brand Name:
Mean Well
Shipping:
Calculated at checkout
Quantity:

Product Description

Mean Well™ HLG Series LED Drivers - IP65 Rated Weatherproof

Mean Well™ power supplies are well-known in the industry for being a highly reliable and low cost way to deliver power to your LED strips. The HLG series powerful and robust and is most often used for outdoor applications. The HLG series can be used with a variety of our single color output, color changing (RGB), color changing + white (RGBW), and Dynamic Tunable Series LED strip lights.

Built to last, they are compatible with the above product's remotes, DC dimmers, and lighting sensors - making it a perfect driver to pair with any of our LED strip lights.

Since the power supply itself is not dimmable, these Mean Well™ power supplies are not compatible with AC input triac dimmers (such as the in-wall Lutron brand dimmers).

This power supply is IP65 rated, has an adjustable voltage and current option, and is protected against short circuiting.

**One note of caution: Mean Well™ LED power supplies do not come with plugs on the AC or DC sides. The bare wires are meant to be hard wired. If you are looking for a plug-and-play power supply, please see our Desktop Style Plug-In Adaptors.

Product Features

  • Electronic Technology
  • Up to 90% Efficiency
  • No Knock-Out Holes
  • Non-dimmable
  • IP65 Outdoor rated
  • Automatic Reset
  • 7 year warranty
  • A type: IP65, adjustable output voltage and constant current level
  • Universal AC input/ Full range (90 ~ 305VAC)
  • Operating Temperature of -40~+70°C
  • Withstand 4kV surge, built-in active PFC function
  • UL / CUL / TUV / PSE / CE certified
  • Type "HL" LED drivers for use in Class I, Division 2 hazardous (Classified) location luminaries
  • Suitable for LED street lighting, outdoor LED lighting, and general outdoor applications with high IP requirement
  • No Primary Breaker (AC) or Secondary Breaker (DC)
  • Output voltage and constant current ranges can be adjusted manually. You can access the tuning ports by removing the rubber stopper on the case.



SPECIFICATIONS

Specifications

Below are specifications for the 12V DC output drivers

Output (Watts) 40 Watts 60 Watts 120 Watts 150 Watts
SKU HLG-40H-12A HLG-80H-12A HLG-120H-12A HLG-150H-12A
Output Voltage 12.0V DC 12.0V DC 12.0V DC 12.0V DC
Max Amperage 3.33A 5A 10A 12.5A
Efficiency 86.50% 88.00% 92.0% 91.50%
Class 2? Yes Yes No No
Dimensions (L*W*H) 6.73" x 2.42" x 1.45" 6.75" x 2.42" x 1.45" 8.67" x 2.68" x 1.53" 8.66 x 2.68 x 1.53"
Output (Watts) 192 Watts 265 Watts 480 Watts
SKU HLG-240H-12A HLG-320H-12A HLG-600H-12A
Output Voltage 12.0V DC 12.0V DC 12.0V DC
Max Amperage 16.0A 22.08A 40A
Efficiency 90.0% 92.50% 92.0%
Class 2? No No No
Dimensions (L*W*H) 9.6" x 2.68" x 1.53" 9 ⅞" x 3 ½" x 1 ¾" 11" x 5 ⅝" x 1 ⅞"

Below are specifications for the 24V DC output drivers:

Output (Watts) 40 Watts 60 Watts 96 Watts 120 Watts
SKU HLG-40H-24A HLG-60H-24A HLG-100H-24A HLG-120H-24A
Output Voltage 24.0V DC 24.0V DC 24.0V DC 24.0V DC
Max Amperage 1.66A 2.5A 4A 5.00A
Efficiency 88.00% 89.50% 93.00% 92.00%
Class 2? Yes Yes No No
Dimensions (L*W*H) 6.73" x 2.42" x 1.45" 6.73" x 2.42" x 1.45" 8.67" x 2.68" x 1.53"

8.66" x 2.68" x 1.53"

Output (Watts) 185 Watts 240 Watts 320 Watts 600 Watts
SKU HLG-185H-24A HLG-240H-24A HLG-320H-24A HLG-600H-24A
Output Voltage 24.0V DC 24.0V DC 24.0V DC 24.0V DC
Max Amperage 7.7A 10.00A 13.34A 25A
Efficiency 93.50% 92.50% 94.00% 95.00%
Class 2? No No No No
Dimensions (L*W*H) 9" x 2.68" x 1.53" 9.6 x 2.68 x 1.53" 9 ⅞" x 3 ½" x 1 ¾" 11" x 5 ⅝" x 1 ⅞"

DOWNLOADS

Downloads

SKUs Link to Data Sheet Link to Installation Guide
HLG-40H-12A HLG-40H-12A HLG-40H-12A
HLG-80H-12A HLG-80H-12A HLG-80H-12A
HLG-120H-12A HLG-120H-12A HLG-120H-12A
HLG-150H-12A HLG-150H-12A HLG-150H-12A
HLG-240H-12A HLG-240H-12A HLG-240H-12A
HLG-320H-12A HLG-320H-12A HLG-320H-12A
HLG-600H-12A HLG-600H-12A HLG-600H-12A
HLG-40H-24A HLG-40H-24A HLG-40H-24A
HLG-60H-24A HLG-60H-24A HLG-60H-24A
HLG-100H-24A HLG-100H-24A HLG-100H-24A
HLG-120H-24A HLG-120H-24A HLG-120H-24A
HLG-185H-24A HLG-185H-24A HLG-185H-24A
HLG-240H-24A HLG-240H-24A HLG-240H-24A
HLG-320H-24A HLG-320H-24A HLG-320H-24A
HLG-600H-24A HLG-600H-24A HLG-600H-24A

FAQ

Frequently Asked Questions

Which Power Supply do I need for my (x) feet of LEDs?
The length of LED strip lights of your project will determine the size of the power supply you need. View our power supply chart to find the exact LED power supply you need.

What do I need to do before installing this power unit?
Remember, an electrician should be consulted before any installations. Line voltage current can be lethal. Be safe! We recommend always following these steps when working with electricity.


  • Turn OFF the circuit using the circuit-breaker at the main electrical panel. Use a marker or tape to notate, or even lock the circuit breaker switch so that someone else doesn't switch it back on while you are working on the wiring
  • Test the area you will be working with a multimeter or voltage tester to make sure electricity is off. After a test confirms a wires are dead, check the equipment has not just now failed. Test it on a known live source before proceeding to handle the wiring
  • Again, always consult an electrician licensed to do electrical work in your area

Can I use a these Mean Well power supplies with a wall dimmer, connected on the AC side?
No, the HLG-A series are not compatible with triac, forward/reverse phase dimmers.
