  • LPV Series Mean Well LED Power Supply

Mean Well™ LPV Series LED Driver [20W - 100W Available]

Shipping:
Calculated at checkout
Quantity:

Product Description

Mean Well™ LPV Series LED Drivers - IP67 Rated Waterproof

Introduction

Mean Well™ power supplies are well-known in the industry for being a highly reliable and low cost way to deliver power to your LED products. Small but powerful, the VPL series is a AC/DC constant voltage adapter that is IP67 waterproof and designed for both indoor and outdoor applications. The LPV series can be used with a variety of our single color output, color changing (RGB), color changing + white (RGBW), and Dynamic Tunable Series LED strip lights.

Built to last, they are compatible with the above product's remotes, DC dimmers, and lighting sensors - making it a perfect driver to pair with any of our LED strip lights.

Since the power supply itself is not dimmable, these Mean Well™ power supplies are not compatible with AC input triac dimmers (such as the in-wall Lutron brand dimmers).

This power supply is IP65 rated, has an adjustable voltage and current option, and is protected against short circuiting.

**One note of caution: Mean Well™ LED power supplies do not come with plugs on the AC or DC sides. The bare wires are meant to be hard wired. If you are looking for a plug-and-play power supply, please see our desktop style power adaptors

Although it is more commonly used for indoor applications as it cannot be installed in areas that are exposed to direct sunlight.

Product Features

  • Electronic technology
  • Universal AC input / full range (up to 264 VAC)
  • Load Capacity up to 90%
  • Withstand 300VAC surge input for 5 seconds (LPV/C-20/35/60/100)
  • Automatic Reset
  • No Knock-Out Holes
  • Non-dimmable; Not compatible with AC in AC out dimmers such as Lutron, Legrand, Leviton dimmers
  • IP67 designed for indoor use or outdoor use without direct sunlight exposure
  • Compatible with all Flexfire LED Strip Lights
  • Recommended to be installed in a well ventilated area
  • Slim PFC plastic casing
  • 3 year warranty
  • Operating Temperature of -30~+70°C
  • UL / CUL / TUV / PSE / CE certified
  • No Primary Breaker (AC) or Secondary Breaker (DC)

SPECIFICATIONS

Specifications

Below are specifications for the 12V DC output drivers

Output (Watts) 20 Watts 35 Watts 60 Watts 100 Watts
SKU LPV-20-12 LPV-35-12 LPV-60-12 LPV-100-12
Output Voltage 12V DC 12V DC 12V DC 12V DC
Max Amperage 1.67A 3A 5A 8.33A
Efficiency 81.00% 84.00% 83.0% 85.00%
Class 2? Yes Yes Yes No
Dimensions (L*W*H) 4.65" x 1.38" x 1.02" 5.83" x 1.57" x 1.18"
5.83" x 1.57" x 1.18" 7.5" x 2" x 1.5"

Below are specifications for the 24V DC output drivers:

Output (Watts) 20 Watts 35 Watts 60 Watts
SKU LPV-20-24 LPV-35-24 LPV-60-24
Output Voltage 24V DC 24V DC 24V DC
Max Amperage 0.84A 1.67A 2.5A
Efficiency 81.00% 84.00% 83.0%
Class 2? Yes Yes Yes
Dimensions (L*W*H) 4.65" x 1.38" x 1.02" 5.83" x 1.57" x 1.18"
5.83" x 1.57" x 1.18"

Mean Well Certifications

DOWNLOADS

Downloads

SKUs Link to Data Sheet Link to Installation Guide
LPV-20-12 LPV-20-12 LPV-20-12
LPV-35-12 LPV-35-12 LPV-35-12
LPV-60-12 LPV-60-12 LPV-60-12
LPV-100-12 LPV-100-12 LPV-100-12
LPV-20-24 LPV-20-24 LPV-20-24
LPV-35-24 LPV-35-24 LPV-35-24
LPV-60-24 LPV-60-24 LPV-60-24

FAQ

Frequently Asked Questions

Which Power Supply do I need for my (x) feet of LEDs?
The length of LED strip lights of your project will determine the size of the power supply you need. View our power supply chart to find the exact LED power supply you need.

What do I need to do before installing this power unit?
Remember, an electrician should be consulted before any installations. Line voltage current can be lethal. Be safe! We recommend always following these steps when working with electricity.


Turn OFF the circuit using the circuit-breaker at the main electrical panel. Use a marker or tape to notate, or even lock the circuit breaker switch so that someone else doesn't switch it back on while you are working on the wiring

Test the area you will be working with a multimeter or voltage tester to make sure electricity is off. After a test confirms a wires are dead, check the equipment has not just now failed. Test it on a known live source before proceeding to handle the wiring

Again, always consult an electrician licensed to do electrical work in your area

Can I use a these Mean Well power supplies with a wall dimmer, connected on the AC side?
No, the LPV series are not compatible with triac, forward/reverse phase dimmers.

Product Reviews


Specifications for this Hybrid LED light kit

Product Hybrid Bright White/Warm White LED Strip Light
Color Temperature 2900K for Warm White and 6500K for Bright White
Lumen (Brightness) 3450 Lumens per reel
Quantity per unit You will receive a continuous 16ft section of lights
UL Listed? Yes UL Listed, Must be used with class 2 power transformer
Working Voltage 12v DC
Dimmability Fully Dimmable
Beam Angle 120 Degrees
Rigid or Flexible?

-Flexible installation up to 90 degrees. Used on curved surfaces

Power consumption 2.92 watts per foot
UV emission No
LED Count per reel 600 LEDs
Warranty

2 years
